22A-A4P5N104 A-B PowerFlex 4 AC Drive
$ 95.67
- Free Delivery Over $30 All Products
- 30 days easy returns if you change your mind
- Order before noon for same day dispatch
Guaranteed Safe Checkout
- Description 22A-A4P5N104 A-B PowerFlex 4 AC Drive Product Dimensions： Product Description (Detailed Explanation) The PowerFlex 4 is engineered to provide powerful motor speed control in a space-saving design. The 22A-A4P5N104 model is specifically designed for 240V single-phase input, converting it to 230V three-phase output. This makes it an ideal choice for small workshops or facilities where three-phase utility power is unavailable. It features an integrated keypad and local potentiometer for easy manual speed adjustment. Its modular design allows for Zero-Stacking™ (mounting drives side-by-side without gaps) to save cabinet space. The drive uses Volts per Hertz ($V/Hz$) control for simple and reliable performance in standard torque applications. Product Parameters (Technical Specifications) Parameter Category Specification Series PowerFlex 4 Part Number 22A-A4P5N104 Power Rating 0.75 kW (1.0 HP) Input Voltage 200-240V AC (±10%), 1-Phase Output Voltage 0-230V AC, 3-Phase Output Current 4.5 Amps Output Frequency 0 to 240 Hz (Programmable) Enclosure Rating IP20 / NEMA UL Type Open Control Mode Volts per Hertz ($V/Hz$) Overload Capacity 150% for 60 seconds; 200% for 3 seconds Communication Integrated RS-485 (Supports Modbus RTU) Mounting Type DIN Rail or Panel Mount Product Advantages (Key Benefits) Compact Footprint: One of the smallest drives in its class, perfect for machine tools and small control panels. Easy Programming: The fixed keypad and organized parameter group (Basic and Advanced) allow for quick out-of-the-box commissioning. Cost-Effective: Provides essential VFD features without the cost of complex high-end vector control units. Energy Efficiency: Includes adjustable PWM frequencies up to 16 kHz to optimize motor noise and efficiency. Zero-Stacking: Can be mounted side-by-side with other PowerFlex 4 drives, significantly reducing the required enclosure width. Precautions (Important Notes) Input Phase Limitation: This specific model is for Single-Phase input only. Do not attempt to wire it to a 3-phase source unless verified by the manual for that specific frame size. Enclosure Protection: As an IP20 / Open Type device, it must be installed inside a secondary enclosure to protect against dust, moisture, and accidental contact with live terminals. Dynamic Braking: This model (N104) does not include an internal brake resistor. If your application involves high-inertia loads requiring fast stops, an external braking module may be required. Grounding: Ensure the drive is properly grounded to the enclosure’s backplate to minimize Electromagnetic Interference (EMI). Motor Protection: While the drive provides electronic motor overload protection, ensure the motor’s nameplate data is correctly entered into the parameters. Product Applications (Typical Use Cases) Conveyors: Smooth starting and speed regulation for material handling belts. Fans & Pumps: Energy savings and flow control in HVAC and small industrial pumping systems. Machine Tools: Speed control for lathes, grinders, and drill presses in light-duty manufacturing. Packaging Machinery: Coordinating small-scale filling, sealing, and labeling equipment. Food Processing: Controlling mixers, blenders, and small-scale ovens. Shipping Port: Xiamen, China Payment: Bank of Chicago, Bank of Singapore Express cooperation: fedex, DHL, UPS and your express account Service: Professional Sales provides 24 hours /7 days online service Please make an inquiry for more models： AB 1756-0B16E AB 1756-DMD30 AB 1756-IB32 AB 1756-0F4 AB 1756-DNB AB 1756-IB32/A AB 1756-0X8I AB 1756-DNB/A AB 1756-IF16 AB 1756-A10 AB 1756-DNB/A/B AB 1756-IF16/A AB 1756-A13 AB 1756-DNB/B AB 1756-IF161 AB 1756-A17 AB 1756-DNB/C1756-DNB/D AB 1756-IF16H AB 1756-A4 AB 1756-DNB/D AB 1756-IF4FXOF2F AB 1756-A7 AB 1756-DNB1 AB 1756-IF6CIS AB 1756-BA11 AB 1756-EN2T AB 1756-IF6I AB 1756-BA2 AB 1756-EN2T/C AB 1756-IF8 AB 1756-CFM AB 1756-EN2T/D AB 1756-IF8H AB 1756-CN2 AB 1756-EN2TR AB 1756-IF8U AB 1756-CN2/B AB 1756-EN2TR/B AB 1756-IG16 AB 1756-CN21 AB 1756-EN3TR AB 1756-IH16I AB 1756-CN2R AB 1756-ENBT AB 1756-IM16I AB 1756-CN2R/B AB 1756-ENBT/A AB 1756-IM16I1203-CN1 AB 1756-CNB AB 1756-ENET AB 1756-IN16 AB 1756-CNB/A/B/C/D AB 1756-EWEB AB 1756-IR6I AB 1756-CNB/D AB 1756-HSC AB 1756-IRT8I AB 1756-CNB/E AB 1756-HSC1 AB 1756-IT6I AB 1756-CNBR AB 1756-HYD02 AB 1756-IT6I2 AB 1756-CNBR/A/D AB 1756-IA16/A AB 1756-IV16 AB 1756-CNBR/D AB 1756-IA32 AB 1756-IV32 AB 1756-CNBR/E AB 1756-IB16 AB 1756-L1M1 AB 1756-CPR2 AB 1756-IB16/A AB 1756-L35E AB 1756-DHRIO AB 1756-IB16D AB 1756-L55M12 AB 1756-DHRIO/C AB 1756-IB16I AB 1756L55M13 AB 1756-DHRIO/D AB 1756-IB16ISOE AB 1756-L55M13 AB 1756-DHRIO/E AB 1756-IB16SOE AB 1756-L55M14 AB 1756L55M22 AB 1756-L55M16 AB 1756L55M16 AB 1756-L55M23 AB 1756L55M23 AB 1756-L55M22
