5V/600mA 100-240V AC-DC Power Regulator Module – HI-LINK HLK-PM01
$ 2.23
- Free Delivery Over $30 All Products
- 30 days easy returns if you change your mind
- Order before noon for same day dispatch
Guaranteed Safe Checkout
- Description This is small 100VAC-240VAC to 5V/600mA 3W DC Sealed Power Regulator Module that is intended for providing DC 5V from Mains 220VAC/230VAC power line. Applications The module is perfect for Powering Sensors such as ESP8266 based WiFi Sensor Digital IP Cameras 5V LED Light bulbs or strips Digital Door Bell Features Product features: ultra-thin, subminiature Low ripple and low noise Output overload short circuit protection function High efficiency and power density Product design to meet the EMC and safety testing requirements Low power consumption, green environmental protection, no-load loss < 0.1 W Cooling method: Natural cooling Technical Specifications Rated input voltage 100-240 VAc Input voltage range 90-264 VAc Maximum input current ≤0.2 A Input current surge : ≤10 A Enter slow start ≤50 mS Input Low Voltage Efficiency Vin=110VAc，Output full-load≥69 % Input High Voltage Efficiency Vin=220VAc，output full-load≥70 % Long-term reliability MTBF≥100，000 h Load rated output voltage 5±0.1 VDc Full rated output voltage 5±0.2 VDc Short-term maximum output current ≥1000 mA Output current for a long time ≥600 mA Voltage Regulation ±0.2 % Load Regulation ±0.5 % Output ripple and noise (mVp-p) ≤50 Rated input voltage, full load. Using 20MHz of bandwidth, The load side 10uF and 0.1uF capacitor to be tested. mV Switch overshoot amplitude (Rated input voltage and output load plus 10%)≤5 %VO Output over-current protection 150-200% of the output maximum load A Output short circuit protection: Direct short circuit at the normal output, automatically resume normal operation after a short circuit removal Documents and Downloads HLK-PM01 Datasheet Package Includes 1x 5V/600mA 100-240V AC-DC Power Regulator Module – HI-LINK HLK-PM01 (Tested and QC-OK)
